POLB HD 60Hz三相圆柱形重负电容器
POLB HD 三相圆柱形重负电容器
10...50 kvar 60Hz (HEAVY DUTY 重负) THREE-PHASE CYLINDRICAL CAPACITOR
Description 产品简介
Heavy Duty (HD series) capacitors are designed to offer long time expectancy and outstanding performance with its higher electrical characteristics.
It is a self-healing capacitor with low losses metallized polypropylene dielectric, filled with inert gas N2. They have an overpressure disconnection system which provides a high level of safety against internal defects cutting the 3 phases.
Capacitors are built in cylindrical aluminum cans, provided with a M12 stud for fixing and earthling. Connection is made by a terminal block with clamp type terminals.
The name plate includes a QR code associated, allowing you to download the individual routine test certificate, and it also offers a copy protection.
重负（HD 系列）电容器旨在提供更高的电气特性、更长的预期寿命和更出色的性能。
它是一种具有低损耗金属化聚丙烯电介质的自愈式电容器，充有惰性气体N2。它还具有超压断开系统，可提供高水平的安全性，防止内部缺陷切断3 相电。
电容器内置于圆柱形铝罐中，配有M12 螺柱用于固定和接地。 通过带有夹式端子的端子块进行连接。
铭牌包括一个相关的二维码，允许您下载个人的例行测试证书，它还提供复制保护。
Technical characteristics 技术参数
• Rated Voltage / 额定电压 ....................................... 230 ... 690V
• Frequency / 频率........................................................... 60 Hz
• Dielectric / 电介质......................................................... Polypropylene 聚丙烯
• Discharge resistors / 放电电阻器.............................. Fitted 适用
• Dielectric losses / 介电损耗......................................≤ 0.2 W/kvar
• Total losses / 总损耗................................................. ≤ 0.4 W/kvar
• Max. Overvoltage / 最大过载点压 ........................ 1.1 Un
• Max. Overcurrent (1) / 最大过载电流 .................. 2 In
• Transient Overcurrent / 瞬时电流............................ 400 In
• Isolation level / 绝缘等级.......................................... 3/8 kV
• Power tolerance / 功率容差 .....................................- 5 / + 10 %
• Climatic range (2) / 温度范围....................................- 40/ D (+60ºC)
• Life expectancy / 预期寿命 .......................................> 150.000 / hours
• Terminal block / 接线端子........................................ Type A 型: 16 mm2 ; 3 Nm max.; Pozidriv head screws
Type B型 : 25 mm2 ; 3 Nm max.; Pozidriv head screws
Type C型 : 35 mm2 ; 3.7 Nm max. Hex socket head screws内六角螺钉
• Protection / 防护等级 ............................................... IP20
IP54 with hood up to带护罩高达 Ø116mm
• Standards / 标准......................................................... IEC 60831, EN 60831, UL 810
UL certification in progress
Remarks : 备注
(1) Maximum current for 48 hours continuous operation. (Tested as per IEC 60831-1:2014 Clause 13). 48 小时连续运行的最大电流
(2) Maximum temperature as per最高温度符合 IEC 60831-1:2014. Clause 4.1
40/D (60 ºC) Refers: 60 ºC Maximum punctual temperature. 最高准时温度
45 ºC Highest mean temperature over any period of 24 h. 24小时内任何时期的最高平均温度
35 ºC Highest mean temperature over any period of a year. 一年中任何时期的最高平均温度
规格型号列表
| Part Number | 60 Hz | Capacitance | Dimensions | Weight | Terminal | |||||
| 230V | 220V | 240V | (μF) | D x L | (kg) | block | ||||
| Qn | In (A) | Qn | In (A) | Qn | In (A) | |||||
| (kvar) | (kvar) | (kvar) | ||||||||
| POLB23025ZHD | 2.5 | 6.3 | 2 | 6 | 3 | 6.5 | 3x62.7 | 85x175 | 0.9 | A |
| POLB23050ZHD | 5 | 12.6 | 4.6 | 12 | 5.4 | 13.1 | 3x125.4 | 85x175 | 1.2 | A |
| POLB23075ZHD | 7.5 | 18.8 | 7 | 18 | 8 | 19.6 | 3x188 | 85x245 | 1.7 | A |
| POLB23100ZHD | 10 | 25.1 | 9 | 24 | 11 | 26.2 | 3x250.7 | 85x245 | 2 | A |
| POLB23125ZHD | 13 | 31.4 | 11 | 30 | 14 | 32.7 | 3x313.4 | 100x245 | 3.3 | A |
| POLB23150ZHD | 15 | 37.7 | 14 | 36 | 16 | 39.3 | 3x376.1 | 100x245 | 3.3 | A |
| Part Number | 60 Hz | Capacitance | Dimensions | Weight | Terminal | |||||
| 440V | 400V | 415V | (μF) | D x L | (kg) | block | ||||
| Qn | In (A) | Qn | In (A) | Qn | In (A) | |||||
| (kvar) | (kvar) | (kvar) | ||||||||
| POLB44100ZHD | 10 | 13.1 | 8 | 11.9 | 9 | 12.4 | 3x68.5 | 85x175 | 1 | A |
| POLB44125ZHD | 12.5 | 16.4 | 10.3 | 14.9 | 11 | 15.5 | 3x85.6 | 85x245 | 1.2 | A |
| POLB44150ZHD | 15 | 19.7 | 13 | 17.9 | 13 | 18.6 | 3x102.8 | 85x245 | 1.3 | A |
| POLB44182ZHD | 18 | 23.6 | 15 | 21.8 | 16 | 22.6 | 3x125 | 85x245 | 1.9 | A |
| POLB44200ZHD | 20 | 26.2 | 16 | 23.9 | 18 | 24.8 | 3x137 | 85x245 | 1.9 | A |
| POLB44250ZHD | 25 | 32.8 | 20 | 29.8 | 22 | 30.9 | 3x171.3 | 100x245 | 2.1 | A |
| POLB44300ZHD | 30 | 39.4 | 25 | 35.8 | 27 | 37.1 | 3x205.5 | 116x245 | 3.3 | B |
| POLB44364ZHD | 36 | 47.2 | 30 | 43.4 | 32.4 | 45 | 3x249.4 | 116x245 | 3.3 | B |
| POLB44400ZHD | 40 | 52.5 | 33 | 47.7 | 36 | 49.5 | 3x274 | 136x220 | 4 | B |
| POLB44500ZHD | 50 | 65.6 | 40 | 59.6 | 44 | 61.9 | 3x342.5 | 136x355 | 5.5 | C |
| POLB40500ZHD | ----- | ----- | 50 | 72.2 | ---- | ---- | 3x342.5 | 136x355 | 5.5 | C |
| Part Number | 60 Hz | Capacitance | Dimensions | Weight | Terminal | |||||
| 460V | 400V | 440V | (μF) | D x L | (kg) | block | ||||
| Qn | In (A) | Qn | In (A) | Qn | In (A) | |||||
| (kvar) | (kvar) | (kvar) | ||||||||
| POLB46025ZHD | 2.5 | 3.1 | 2 | 2.7 | 2 | 3 | 3x15.7 | 85x175 | 0.9 | A |
| POLB46050ZHD | 5 | 6.3 | 3.8 | 5.5 | 4.6 | 6 | 3x31.3 | 85x175 | 0.9 | A |
| POLB46075ZHD | 7.5 | 9.4 | 6 | 8.2 | 7 | 9 | 3x47 | 85x175 | 1.1 | A |
| POLB46100ZHD | 10 | 12.6 | 8 | 10.9 | 9 | 12 | 3x62.7 | 85x245 | 1.1 | A |
| POLB46125ZHD | 13 | 15.7 | 9 | 13.6 | 11 | 15 | 3x78.3 | 85x245 | 1.2 | A |
| POLB46150ZHD | 15 | 18.8 | 11 | 16.4 | 14 | 18 | 3x94 | 85x245 | 1.4 | A |
| POLB46200ZHD | 20 | 25.1 | 15 | 21.8 | 18 | 24 | 3x125.4 | 100x245 | 1.9 | A |
| POLB46250ZHD | 25 | 31.4 | 18.9 | 27.3 | 22.9 | 30 | 3x156.7 | 100x245 | 2.1 | A |
| POLB46300ZHD | 30 | 37.7 | 23 | 32.7 | 27 | 36 | 3x188 | 116x245 | 3 | B |
| Part Number | 60 Hz | Capacitance | Dimensions | Weight | Terminal | |||||
| 480V | 500V | 525V | (μF) | D x L | (kg) | block | ||||
| Qn | In (A) | Qn | In (A) | Qn | In (A) | |||||
| (kvar) | (kvar) | (kvar) | ||||||||
| POLB48025ZHD | 2.5 | 3 | 3 | 3.1 | 3 | 3.3 | 3×14.4 | 85×175 | 0.6 | A |
| POLB48050ZHD | 5 | 6 | 5.4 | 6.3 | 6 | 6.6 | 3×28,8 | 85×175 | 0.8 | A |
| POLB48075ZHD | 7.5 | 9 | 8 | 9.4 | 9 | 9.9 | 3×43.2 | 85×175 | 0.9 | A |
| POLB48100ZHD | 10 | 12 | 11 | 12.5 | 12 | 13.2 | 3×57.6 | 85×245 | 1.1 | A |
| POLB48125ZHD | 13 | 15 | 14 | 15.7 | 15 | 16.4 | 3×72 | 85×245 | 1.1 | A |
| POLB48150ZHD | 15 | 18 | 16 | 18.8 | 18 | 19.7 | 3×86.3 | 85×245 | 1.4 | A |
| POLB48200ZHD | 20 | 24.1 | 22 | 25.1 | 24 | 26.3 | 3×115,1 | 100×245 | 2.1 | A |
| POLB48250ZHD | 25 | 30.1 | 27 | 31.3 | 30 | 32.9 | 3×143.9 | 116×245 | 2.2 | B |
| POLB48300ZHD | 30 | 36.1 | 33 | 37.6 | 36 | 39.5 | 3×172.7 | 116×245 | 2.7 | B |
| POLB48400ZHD | 40 | 48.1 | 43.4 | 50.1 | 48 | 52.6 | 3×230.3 | 136×261 | 3.5 | B |
| POLB48500ZHD | 50 | 60.1 | 54 | 62.6 | 60 | 65.8 | 3×287.8 | 136×355 | 5.6 | C |
| Part Number | 60 Hz | Capacitance | Dimensions | Weight | Terminal | |||||
| 600V | 660V | 690V | (μF) | D x L | (kg) | block | ||||
| Qn | In (A) | Qn | In (A) | Qn | In (A) | |||||
| (kvar) | (kvar) | (kvar) | ||||||||
| POLB60050ZHD | 5 | 4.8 | 6 | 5.3 | 7 | 5.5 | 3×18.4 | 85×175 | 0.8 | A |
| POLB60062ZHD | 6 | 6 | 8 | 6.6 | 8 | 6.9 | 3×23.0 | 85×175 | 0.9 | A |
| POLB60100ZHD | 10 | 9.6 | 12 | 10.6 | 13 | 11.1 | 3×36.8 | 85×245 | 1 | A |
| POLB60125ZHD | 13 | 12 | 15 | 13.2 | 17 | 13.8 | 3×46.1 | 85×245 | 1.2 | A |
| POLB60150ZHD | 15 | 14.4 | 18 | 15.9 | 20 | 16.6 | 3×55.3 | 100×245 | 1.8 | A |
| POLB60200ZHD | 20 | 19.2 | 24.2 | 21.2 | 26.5 | 22.1 | 3×73.7 | 116×245 | 1.9 | B |
| POLB60250ZHD | 25 | 24.1 | 30 | 26.5 | 33 | 27.7 | 3×92.1 | 116×245 | 2.1 | B |
| POLB60300ZHD | 30 | 28.9 | 36.3 | 31.8 | 39.7 | 33.2 | 3×110.5 | 136×220 | 3.3 | B |
| POLB60400ZHD | 40 | 38.5 | 48 | 42.3 | 53 | 44.3 | 3×147.4 | 136×355 | 5.6 | C |
| Part Number | Description | |||||||||
| H19090601 | Plastic protection cover for d=85 mm.(incl. Gland Ref: CT14001) | |||||||||
| H19100601 | Plastic protection cover for d=100 mm | |||||||||
| H19116601 | Plastic protection cover for d=110 mm and d=116 (incl. gland) | |||||||||
